Description

Step into the era of next-level automation with Jimmy Technology’s 190 Series Long Stroke Servo Electric Cylinder—your answer for when brute force must meet surgical precision. Engineered to handle the heaviest loads with seamless accuracy, this high force servo cylinder is the modern alternative to bulky hydraulic systems, empowering you to take control of 20-ton applications with the quiet, clean versatility only electric linear actuators provide.

Features and Benefits

Rugged 20-Ton Load Capability
Built for the toughest industrial automation components, this heavy duty electric cylinder can deliver and sustain a massive 20T force output—perfect for extreme load applications, high cycle life actuator requirements, and dynamic load capacity scenarios. High-grade steel and precision-machined parts offer unyielding durability under continuous industrial stress.
Long Stroke, No Compromises
Experience unmatched long stroke linear motion with available extended stroke lengths—engineered for large-scale pressing applications, material handling solutions, and assembly automation. Never let your motion control systems fall short again.
Servo-Electric Brilliance
Leverage servo motor driven actuator technology: enjoy repeatability accuracy to ±0.01mm, lightning-fast response times, and programmable force control actuator profiles. Absolute encoder feedback and advanced position control actuator features assure precise, smooth, and consistent performance—ideal for testing equipment, forming applications, and precision automation.
Built to Brave Harsh Environments
With a robust IP65 rated cylinder chassis—featuring corrosion-resistant coatings and seals—you’re assured sustained protection in dusty, wet, or washdown conditions. It’s clean room compatible, resists contaminants, and is ready for outdoor duty.
Plug-and-Play Integration
Designed for seamless integration into modern motion control systems, it supports EtherCAT, PROFINET, Modbus TCP/IP, PLC integration, and HMI control. Flexible mounting options such as flange mount cylinder, trunnion mount cylinder, or customizable rod end options make installation painless and future modifications frictionless.

Wide Applications

Whether you’re revolutionizing automotive manufacturing, upgrading material handling, boosting aerospace manufacturing, or running high-precision testing labs, the 190 Series is your go-to electromechanical cylinder. You’ll see its impact in automotive chassis assembly, heavy industrial presses, robotics components, and smarter smart factory components everywhere you look.

Specifications

Force: Up to 20 metric tons (20T) static and dynamic load capacity
Speed: Programmable velocity control; tailored for high speed electric cylinder needs
Stroke Length: Customizable long stroke options to fit extreme load applications
Input Voltage: Multi-voltage servo motor options available
Protection Rating: IP65 rated cylinder housing; dust and water jet resistant

Technical Support

We’ve got your back. Jimmy Technology offers comprehensive technical support—including detailed CAD models, technical data sheet 190 series, performance curves electric cylinder charts, and wiring diagrams. Sizing electric cylinders and system integration challenges? Our team provides full application engineering support to ensure seamless factory automation solutions.

Conclusion

Choose Jimmy Technology’s 190 Series Long Stroke Servo Electric Cylinder and you’re investing in high-force, high-precision performance that redefines reliability for every demanding automation challenge.
